US Motors Three Phase Motor (HVAC/R) D34P2AH - 3/4 HP - 208-230/460 V - 1725 RPM - Three phase

US Motors Three Phase Motor (HVAC/R) D34P2AH - 3/4 HP - 208-230/460 V - 1725 RPM - Three phase

$287.00 CAD
$287.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : D34P2AH

Brand : US Motors

HVAC : Three Phase Motor (HVAC/R)

Horsepower : 3/4 HP

RPM : 1725

Voltage : 208-230/460 V

Phase : Three

Frame : 56

Mounting : Rigid Base

  • Horsepower :3/4
  • Voltage :208-230/460
  • Amps :2.8-2.8/1.4
  • RPM :1725
  • Frequency :50/60 Hz
  • "C" Dim. :10.03"
  • Enclosure :ODP
  • Shaft Dim. :5/8" X 1-7/8"
  • Type :Three Phase
  • Frame :56
  • Bearings :Ball
  • Rotation :Reversible
  • Service Factor :1.25
  • Phase :3
  • Ambient Temp. :40°C
  • Feature(s) :Rolled Steel Frame
  • Weight (lbs.) :25
