US Motors Single Phase Motor (HVAC/R) D2CPA2PH - 2 HP - 115/230 V - 1800 RPM - Single phase

US Motors Single Phase Motor (HVAC/R) D2CPA2PH - 2 HP - 115/230 V - 1800 RPM - Single phase

$559.00 CAD
$559.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : D2CPA2PH

Brand : US Motors

HVAC : Single Phase Motor (HVAC/R)

Horsepower : 2 HP

RPM : 1800

Voltage : 115/230 V

Phase : Single

Frame : 56H

Mounting : Resilient Base

  • Horsepower :2
  • Stack :4.25
  • Voltage :115/230
  • Amps :17.0/8.5
  • RPM :1800
  • Frequency :60 Hz
  • "C" Dim. :13-1/2"
  • Enclosure :Open Drip Proof
  • Shaft Dim. :5/8" x 1-7/8"
  • Type :Capacitor Start
  • Speeds :1
  • Frame :56H
  • Base :Rigid
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.15
  • Phase :1
  • Ambient Temp. :40°C
  • Feature(s) :Class 'B' Insulation
  • Weight (lbs.) :46
