US Motors Fan & Blower Motors (HVAC/R) 6316 - 1 HP - 208/230 V - 1800/1200 RPM Single phase

US Motors Fan & Blower Motors (HVAC/R) 6316 - 1 HP - 208/230 V - 1800/1200 RPM Single phase

$1,033.00 CAD
$1,033.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 6316

Brand : US Motors

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1 HP

RPM : 1800/1200

Voltage : 208/230 V

Phase : Single

Frame : 56

Mounting : Resilient Base

  • Horsepower :1 - 1/3
  • Voltage :208/230
  • Amps :7.40-7.40/4.00-4.30
  • RPM :1800/1200
  • Frequency :60 Hz
  • "C" Dim. :11.80"
  • Enclosure :Open Drip-Proof
  • Shaft Dim. :5/8" x 1.88"
  • Type :Capacitor Start/Capacitor Run
  • Speeds :2
  • Diameter :6-1/2"
  • Frame :56
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :None
  • Service Factor :1.15
  • Phase :1
  • Ambient Temp. :40°C
  • Feature(s) :Class 'B' Insulation, Resilient Base
  • Weight (lbs.) :32
  • Reference : Emerson S63ZZJMS7374
