US Motors Fan & Blower Motors (HVAC/R) 4745 - 1/3 HP - 115 V - 1650 RPM - Single phase

US Motors Fan & Blower Motors (HVAC/R) 4745 - 1/3 HP - 115 V - 1650 RPM - Single phase

$286.00 CAD
$286.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 4745

Brand : US Motors

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/3 HP

RPM : 1650

Voltage : 115 V

Phase : Single

Frame : 48Y

Mounting : Stud Mount

  • Horsepower :1/3
  • Voltage :115
  • Amps :4.00
  • RPM :1650
  • Frequency :60 Hz
  • Length :6.06"
  • "C" Dim. :9.31"
  • Enclosure :Open Air Over
  • Shaft Dim. :1/2" x 3.25"
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Diameter :5-5/8"
  • Frame :48Y
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :40°C
  • Feature(s) :Thru-Bolts, Stud Mounting
  • Weight (lbs.) :13

  • Reference : K55HXEZS7589
    Manufacturer Model # : K055EZS7589022B
