Morrill ECM Motors (HVAC/R) 5201A - 1/15 HP - 208/230 V - 1550 RPM - Single phase

Morrill ECM Motors (HVAC/R) 5201A - 1/15 HP - 208/230 V - 1550 RPM - Single phase

$169.00 CAD
$169.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 5201A

Brand : Morrill

HVAC : ECM Motors (HVAC/R)

Horsepower : 1/15 HP

RPM : 1550

Voltage : 208/230 V

Phase : Single

Frame : 3.3

Mounting : Stud Mount

  • Horsepower :1/15
  • Voltage :208-230
  • Amps :0.8
  • RPM :1550
  • Frequency :50/60 Hz
  • "C" Dim. :6.74"
  • Enclosure :Totally Enclosed
  • Shaft Dim. :5/16" X 2-5/8"
  • Type :Electronically Commutated
  • Speeds :1
  • Diameter :3.3"
  • Bearings :Ball
  • Rotation :CWSE
  • Phase :1
  • Ambient Temp. :-40°C to 55°C
  • Feature(s) :24" Cord set attached to motor
  • Weight (lbs.) :11
  • Reference : 5SME59BVA2039
