Leeson General Purpose Motors (HVAC/R) C1152 - 1/2 HP - 115/230 V - 3450 RPM - Single phase

Leeson General Purpose Motors (HVAC/R) C1152 - 1/2 HP - 115/230 V - 3450 RPM - Single phase

$324.00 CAD
$324.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : C1152

Brand : Leeson

HVAC : General Purpose Motors (HVAC/R)

Horsepower : 1/2 HP

RPM : 3450

Voltage : 115/230 V

Phase : Single

Frame : 48

Mounting : Resilient Base

  • Horsepower :1/2
  • Voltage :115/230
  • Amps :8.3/3.9-4.1
  • RPM :3450
  • Frequency :60 Hz
  • "C" Dim. :11.00"
  • Enclosure :Open Drip Proof
  • Type :Capacitor Start
  • Speeds :1
  • Frame :48
  • Base :Rigid
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.25
  • Phase :1
  • Ambient Temp. :40°C
  • Weight (lbs.) :19
  • Reference : Century B590, Dayton 3K092 6K804, General Electric C1152 5KC39QN3220
