Leeson Unit Heater Motors (HVAC/R) X304 - 1/3 HP - 115 V - 1075 RPM - Single phase

Leeson Unit Heater Motors (HVAC/R) X304 - 1/3 HP - 115 V - 1075 RPM - Single phase

$318.00 CAD
$318.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : X304

Brand : Leeson

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/3 HP

RPM : 1075

Voltage : 115 V

Phase : Single

Frame : 48Y

Mounting : Resilient Base

  • Horsepower :1/3
  • Voltage :115
  • Amps :6.5
  • RPM :1075
  • Frequency :60 Hz
  • "C" Dim. :9.75
  • Enclosure :Totally Enclosed Air Over
  • Shaft Dim. :1/2" x 2-3/4"
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Frame :48Y
  • Base :Resilient
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.0
  • Phase :1
  • Ambient Temp. :40°C
  • Weight (lbs.) :21
  • Reference : A.O.Smith F48Y58A01, Marathon 48A11T201K, Century 732A 152664 177328, Century Catalogue C748, Dayton 3M835, Emerson K55HXHPY8817, General Electric 3J64BBX 4J309LAX 4J392BX
