Leeson Unit Heater Motors (HVAC/R) X303 - 1/6 HP - 115 V - 1075 RPM - Single phase

Leeson Unit Heater Motors (HVAC/R) X303 - 1/6 HP - 115 V - 1075 RPM - Single phase

$339.00 CAD
$339.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : X303

Brand : Leeson

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/6 HP

RPM : 1075

Voltage : 115 V

Phase : Single

Frame : 48Y

Mounting : Resilient Base

  • Horsepower :1/6
  • Voltage :115
  • Amps :4.1
  • RPM :1075
  • Frequency :60 Hz
  • "C" Dim. :8.5"
  • Enclosure :Totally Enclosed Air Over
  • Shaft Dim. :1/2" x 2-3/4"
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Frame :48Y
  • Base :Resilient
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.0
  • Phase :1
  • Ambient Temp. :40°C
  • Weight (lbs.) :14
  • Reference : Model: 48A11T198K, Century 566 734A UH1026
