Leeson Belted Fan Motors (HVAC/R) C216 - 1/3 HP - 115/208-230 V - 1725 RPM - Single phase

Leeson Belted Fan Motors (HVAC/R) C216 - 1/3 HP - 115/208-230 V - 1725 RPM - Single phase

$439.00 CAD
$439.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : C216

Brand : Leeson

HVAC : Belted Fan Motors (HVAC/R)

Horsepower : 1/3 HP

RPM : 1725

Voltage : 115/208-230 V

Phase : Single

Frame : 56

Mounting : Resilient Base

Type : Capacitor Start
HP : 1/3
Voltage : 115 / 208-230
RPM : 1725
Current (Amp) : 6.00 / 3.20-3.00
Phase : 1
Rotation : Reversible
Frame : 56
Enclosure : Drip Proof
Speeds : 1
Protector : Automatic
Ambient Temp : 40°C
Service Factor : 1.35
Shaft Dimensions : 0.625 in X 1.88 in
Frequency : 60Hz
Diameter : 6.5 in
Frame Length : 10.32 in
Bearings : Ball

Weight: 18 lbs
Reference : A.O. Smith RB1034A, Dayton 4K708 2K510 4K102 6K366, General Electric 5KC36LN1, Marathon B210
