Fasco OEM Replacement Motors (HVAC/R) D1101 - 1/20 HP - 115 V - 1500 RPM - Single phase

Fasco OEM Replacement Motors (HVAC/R) D1101 - 1/20 HP - 115 V - 1500 RPM - Single phase

$141.00 CAD
$141.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : D1101

Brand : Fasco

HVAC : OEM Replacement Motors (HVAC/R)

Horsepower : 1/20 HP

RPM : 1500

Voltage : 115 V

Phase : Single

Frame : 3.3

Mounting : Stud Mount

  • Horsepower :1/20
  • Voltage :115
  • Amps :1.90
  • RPM :1500
  • Frequency :60 Hz
  • Length :2-3/4"
  • Enclosure :Open
  • Shaft Dim. :5/16" x 2-1/4"
  • Type :Shaded Pole
  • Speeds :1
  • Diameter :3.3"
  • Bearings :Sleeve
  • Rotation :CCWSE
  • Protector :Automatic
  • Service Factor :1.00
  • Phase :1
  • Feature(s) :Thru-Bolts, Shell Turbo 68, Low Temp. Oil (-40°F)
  • Weight (lbs.) :3

  • Reference : A.O. Smith 574, Larkin No. 253-1194, Fasco No. 7163-2113 7163-4259 7163-4463 7163-5604 7163-7469 7163-7495, General Electric 5KSM59ES2405CS 5KSM59ES3443AS, Shell Turbo 68 low temp, 80574, Universal Electric JA2N015N JA2N184 JA2N267N JA2S078
