Fasco Fan & Blower Motors (HVAC/R) D503 - 1/10 HP - 230 V - 1590 RPM - Single phase

Fasco Fan & Blower Motors (HVAC/R) D503 - 1/10 HP - 230 V - 1590 RPM - Single phase

$329.00 CAD
$329.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : D503

Brand : Fasco

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/10 HP

RPM : 1590

Voltage : 230 V

Phase : Single

Frame : 3.3

Mounting : Stud Mount

  • Horsepower :1/10
  • Voltage :230
  • Amps :1
  • RPM :1590
  • Frequency :60 Hz
  • "C" Dim. :8.77"
  • Enclosure :Open Air Over
  • Shaft Dim. :5/16" x 3-7/8"
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Diameter :3.3"
  • Bearings :Sleeve
  • Rotation :Reversible
  • Protector :Thermal
  • Service Factor :1
  • Phase :1
  • Ambient Temp. :40°C
  • Weight (lbs.) :6
  • Reference : A.O.Smith Century 993, Fasco 7190-1052 7190-0276, 827360100, 2N1803
