Fasco Fan & Blower Motors (HVAC/R) D188 - 1/20 HP - 230 V - 1500 RPM - Single phase

Fasco Fan & Blower Motors (HVAC/R) D188 - 1/20 HP - 230 V - 1500 RPM - Single phase

$134.00 CAD
$134.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : D188

Brand : Fasco

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/20 HP

RPM : 1500

Voltage : 230 V

Phase : Single

Frame : 3.3

Mounting : Stud Mount

  • Horsepower :1/20
  • Voltage :230
  • Amps :0.9
  • RPM :1500
  • Frequency :60 Hz
  • "C" Dim. :5.47"
  • Enclosure :Open Air Over
  • Shaft Dim. :5/16" x 2-3/8"
  • Type :Shaded Pole
  • Speeds :1
  • Diameter :3.3"
  • Bearings :Sleeve
  • Rotation :CWSE
  • Protector :Thermal
  • Service Factor :1
  • Phase :1
  • Ambient Temp. :40°C
  • Weight (lbs.) :3

  • Reference : A.O. Smith 396, Electrohome 286851306 2868511015 2868513016 8213927011, Fasco 7163-2576 7163-4263 7063-9804 7163-2576 7163-4263, General Electric 5KSM84DFK147AS, Rotom R90188, Universal Electric AA2F025N AA2F032N AA2G005 AA2G011 AA2G022A AA2G033N AA2G088K JA2P091 JA2R100 JA2R120 JA2R136 JA2R140 JA2R151 JA2R162 JA2R218 JA2R299N JB2R044
