Fasco Fan & Blower Motors (HVAC/R) D125 - 1/50 HP - 115 V - 1500 RPM - Single phase

Fasco Fan & Blower Motors (HVAC/R) D125 - 1/50 HP - 115 V - 1500 RPM - Single phase

$105.00 CAD
$105.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : D125

Brand : Fasco

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/50 HP

RPM : 1500

Voltage : 115 V

Phase : Single

Frame : 3.3

Mounting : Stud Mount

• HP: 1/50
• Voltage: 115
• RPM: 1500
• AMPs: 0.8
• Phase: 1
• Rotation: CCWSE
• Frame: 3.3
• Enclosure: Totally Enclosed Air Over
• Speeds: 1
• Protector: Thermally Protected
• Ambient Temp: 40°C
• Service Factor: 1
• Shaft Dimensions: 1/4"X2.30"
• Frequency: 60Hz
• Diameter: 3.3"
• Length: 2.24"
• Bearings: Sleeve
• Features: CLASS B INSUL, 12" LEADS, EXTENDED STUDS BOTH SIDES, BELLY BAND MOUNT
• Weight: 3 lbs
• Reference : A.O. Smith 21, Electrohome 2868405117 2868405187 Fasco 7163-1285 7163-1287 7163-3072 7163-3179 7163-3474, Rotom R225 R9021, 19U 21U, 2N10201 2N11601, Universal Electric AA2E018 AA2E032 AA2E049 AA2E057 AA2E060 AA2E107 AA2E110 AA2E122 AA2E134 AA2E138 AA2E163 AA2E165 AA2E182 AA2ELH2 AA2ELH6 AA2G024N AA2G125 JA2M118N JA2M612N
