Emotortek Fan & Blower Motors (HVAC/R) D210-0 - 1/25 HP - 115 V - 3000 RPM - Single phase

Emotortek Fan & Blower Motors (HVAC/R) D210-0 - 1/25 HP - 115 V - 3000 RPM - Single phase

$144.00 CAD
$144.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : D210-0

Brand : Emotortek

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/25 HP

RPM : 3000

Voltage : 115 V

Phase : Single

Frame : 3.3

Mounting : Thru-Bolt Mount

  • Horsepower :1/25
  • Voltage :115
  • Amps :1.30
  • RPM :3000
  • Frequency :60 Hz
  • Length :3-3/32"
  • Enclosure :Open
  • Shaft Dim. :1/4" x 2-1/4"
  • Type :Shaded Pole
  • Speeds :1
  • Diameter :3-3/8"
  • Bearings :Sleeve
  • Rotation :CWSE
  • Protector :Automatic
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :40°C
  • Feature(s) :Thru-Bolts
  • Weight (lbs.) :3.4
  • Reference ; Fasco D210 7121-1578 7121-3691 7021-7185 7121-1994 7121-3469 7121-6697, OmniDrive 8211915118 SS307, Electrohome 2862405052 2862407017 2862407023 2862407024 2862407025 2862407026, Franklin Bluffton 8211210110 8211517010 8211710120, Rotom R307
