US Motors Condenser Fan Motors (HVAC/R) 3738H - 1/2 HP - 460 V - 1075 RPM - Single phase

US Motors Condenser Fan Motors (HVAC/R) 3738H - 1/2 HP - 460 V - 1075 RPM - Single phase

$350.00 CAD
$350.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 3738H

Brand : US Motors

HVAC : Condenser Fan Motors (HVAC/R)

Horsepower : 1/2 HP

RPM : 1075

Voltage : 460 V

Phase : Single

Frame : 48

Mounting : Stud Mount

  • Horsepower : 1/2
  • RPM : 1075
  • Volts : 460
  • Amps : 1.50
  • Frequency : 60 Hz
  • Length : 5-13/16"
  • Enclosure : Totally Enclosed Air Over
  • Shaft Dim. : 1/2” x 6.00”
  • Type : Permanent Split Capacitor
  • Speeds : 1
  • Diameter : 5-5/8"
  • Bearings : Ball
  • Rotation : Reversible
  • Protector : Automatic
  • Service Factor : 1.00
  • Ambient Temp. : 70°C
  • Weight (lbs.) : 18
  • Référence : A.O. Smith F48AF94A01, Century FEH1056SU, Emerson K55ZZWGF947, Marathon X458, U.S. Motors 3738H
