Century Unit Heater Motors (HVAC/R) 734A - 1/4 HP - 115 V - 1135 RPM - Single phase

Century Unit Heater Motors (HVAC/R) 734A - 1/4 HP - 115 V - 1135 RPM - Single phase

$454.00 CAD
$454.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 734A

Brand : Century

HVAC : Unit Heater Motors (HVAC/R)

Horsepower : 1/4 HP

RPM : 1135

Voltage : 115 V

Phase : Single

Frame : 48Y

Mounting : Resilient Base

  • Horsepower :1/4
  • Voltage :115
  • Amps :4.50
  • RPM :1135
  • Frequency :60 Hz
  • Length :5.00"
  • "C" Dim. :8-3/8"
  • Enclosure :Totally Enclosed Air Over
  • Shaft Dim. :1/2" x 3-3/8"
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Diameter :5-5/8"
  • Frame :48Y
  • Bearings :Sleeve
  • Rotation :CCWLE
  • Protector :Automatic
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :60°C
  • Capacitor Rating :5MFD-370VAC
  • Feature(s) :Class 'B Insulation, Resilient Base
  • Weight (lbs.) :16
  • Reference : Universal Electric HE3H7297, A.O. Smith 734, A.O. Smith F48Z17A01, Century 159003, Century C041, Universal Electric C041, Universal Electric HE3J209
