Century Three Phase Motor (HVAC/R) H952 - 2 HP - 575 V - 3450 RPM - Three phase

Century Three Phase Motor (HVAC/R) H952 - 2 HP - 575 V - 3450 RPM - Three phase

$645.00 CAD
$645.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : H952

Brand : Century

HVAC : Three Phase Motor (HVAC/R)

Horsepower : 2 HP

RPM : 3450

Voltage : 575 V

Phase : Three

Frame : 56H

Mounting : Resilient Base

  • Horsepower :2
  • Voltage :575
  • Amps :2.40
  • RPM :3450
  • Frequency :60 Hz
  • Length :12"
  • "C" Dim. :13-29/32"
  • Enclosure :Open Drip-Proof
  • Shaft Dim. :5/8” x 1-7/8"
  • Type :Three Phase
  • Speeds :1
  • Diameter :6-1/2"
  • Frame :56H
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.20
  • Phase :3
  • Ambient Temp. :40°C
  • Feature(s) :Resilient Base, Class 'B' Insulation
  • Weight (lbs.) :37
  • Reference : A.O. Smith 5BK3202, Century 164570 164602, Marathon 56T34D5566, Rotom T2157, 111961
