Century Pedestal Fan Motors (HVAC/R) 486A - 1/4 HP - 115 V - 1100 RPM - Single phase

Century Pedestal Fan Motors (HVAC/R) 486A - 1/4 HP - 115 V - 1100 RPM - Single phase

$339.00 CAD
$339.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 486A

Brand : Century

HVAC : Pedestal Fan Motors (HVAC/R)

Horsepower : 1/4 HP

RPM : 1100

Voltage : 115 V

Phase : Single

Frame : 48Y

Mounting : Yoke Mount

  • Horsepower :1/4
  • Voltage :115
  • Amps :3.20
  • RPM :1100
  • Frequency :60 Hz
  • "C" Dim. :10-3/8"
  • Enclosure :Totally Enclosed Air Over
  • Shaft Dim. :1/2" x 3"
  • Type :Permanent Split Capacitor
  • Speeds :2
  • Diameter :5-5/8"
  • Frame :48Y
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :60°C
  • Capacitor Rating :5MFD-370V
  • Feature(s) :Class 'B' Insulation, Yoke mounting, Thru-Bolt
  • Weight (lbs.) :21
