Century General Purpose Motors (HVAC/R) H954 - 3 HP - 575 V - 3450 RPM - Three phase

Century General Purpose Motors (HVAC/R) H954 - 3 HP - 575 V - 3450 RPM - Three phase

$750.00 CAD
$750.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : H954

Brand : Century

HVAC : General Purpose Motors (HVAC/R)

Horsepower : 3 HP

RPM : 3450

Voltage : 575 V

Phase : Three

Frame : 56HZ

Mounting : Resilient Base

  • Horsepower :3
  • Voltage :575
  • Amps :3.60
  • RPM :3450
  • Frequency :60 Hz
  • Length :11-1/2"
  • "C" Dim. :13-3/4"
  • Enclosure :Open Drip-Proof
  • Shaft Dim. :7/8" x 2-5/16"
  • Type :Three Phase
  • Speeds :1
  • Diameter :6-1/2"
  • Frame :56HZ
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.15
  • Phase :3
  • Ambient Temp. :40°C
  • Feature(s) :Keyed Shaft, Resilient Base, Horizontal Mount only, Class 'B' Insulation
  • Weight (lbs.) :37

  • Reference : A.O. Smith 164568, A.O. Smith 5BK3302, A.O. Smith P56P2T11B2, Century 164568, General Electric 5K49TG1989 5K49TG1989X 5K49TN2163X, Marathon 56T34D15568, P56P2T11B2
