Century General Purpose Motors (HVAC/R) H944 - 1.5 HP - 575 V - 3450 RPM - Three phase

Century General Purpose Motors (HVAC/R) H944 - 1.5 HP - 575 V - 3450 RPM - Three phase

$861.00 CAD
$861.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : H944

Brand : Century

HVAC : General Purpose Motors (HVAC/R)

Horsepower : 1.5 HP

RPM : 3450

Voltage : 575 V

Phase : Three

Frame : 56H

Mounting : Resilient Base

  • Horsepower :1-1/2
  • Voltage :575
  • Amps :1.80
  • RPM :3450
  • Frequency :60 Hz
  • Length :11.00"
  • "C" Dim. :12-29/32"
  • Enclosure :Open Drip Proof
  • Shaft Dim. :5/8" x 1-7/8"
  • Type :Three Phase
  • Speeds :1
  • Diameter :6-1/2"
  • Frame :56H
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.15
  • Phase :3
  • Ambient Temp. :40°C
  • Feature(s) :Class 'B' Insulation, Resilient Base, Continuous Duty, Quick Connect Design Bracket, Horizontal Mount Only
  • Weight (lbs.) :28
