Century General Purpose Motors (HVAC/R) C412V - 1/2 HP - 115/230 V - 1725 RPM - Single phase

Century General Purpose Motors (HVAC/R) C412V - 1/2 HP - 115/230 V - 1725 RPM - Single phase

$362.00 CAD
$362.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : C412V

Brand : Century

HVAC : General Purpose Motors (HVAC/R)

Horsepower : 1/2 HP

RPM : 1725

Voltage : 115/230 V

Phase : Single

Frame : 56

Mounting : Resilient Base

  • Horsepower :1/2
  • Voltage :115/230
  • Amps :9.0/4.0-4.5
  • RPM :1725
  • Frequency :60 Hz
  • Length :9-1/8"
  • "C" Dim. :11-1/8"
  • Enclosure :Open Drip-Proof
  • Shaft Dim. :5/8” x 1-7/8"
  • Type :Capacitor Start
  • Speeds :1
  • Diameter :6-1/2"
  • Frame :56
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.25
  • Phase :1
  • Ambient Temp. :40°C
  • Feature(s) :Resilient Base, Class 'B' Insulation, High Starting Torque, Extended Thru-Bolts - Shaft End Only
  • Weight (lbs.) :26
  • Reference : A.O.Smith Stock No. RB1054A, Baldor RL1304A, Century 107533 111841 165565 193916, Dayton 4UB59, Emerson C63CXERF3690 C63JXSCM3771, Emerson Stock No. 3874, Fasco Stock No. D6084, Franklin Bluffton 1101900700, General Electric 4J205DBY 5KC43MG827 5KC49GN0001 5KCR38RNB463 5KH36MN199, Marathon B317, OmniDrive BTN56RC17D1/2M, 10503
