Century Fan & Blower Motors (HVAC/R) RB2024 - 1/4 HP - 115 V - 1725 RPM - Single phase

Century Fan & Blower Motors (HVAC/R) RB2024 - 1/4 HP - 115 V - 1725 RPM - Single phase

$221.00 CAD
$221.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : RB2024

Brand : Century

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/4 HP

RPM : 1725

Voltage : 115 V

Phase : Single

Frame : 48

Mounting : Resilient Base

  • Horsepower :1/4
  • Voltage :115
  • Amps :5.00
  • RPM :1725
  • Frequency :60 Hz
  • Length :7-13/16”
  • "C" Dim. :9-13/32"
  • Enclosure :Open
  • Shaft Dim. :1/2” x 1-1/2”
  • Type :Split Phase
  • Speeds :1
  • Diameter :5-5/8”
  • Frame :48
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.35
  • Phase :1
  • Ambient Temp. :40°C
  • Feature(s) :Class 'B' Insulation, 1/2” to 5/8” Sleeve & Key Included, Resilient Base, Continuous Duty
  • Weight (lbs.) :14

  • Reference : A.O. Smith 309P409, A.O. Smith 316P159, A.O. Smith 316P299, A.O. Smith 316P341, A.O. Smith 325P189, Century F332, A.O. Smith S48G4CA11, Emerson 2889, GE 4305, Packard 71265, Marathon B303
