Century Fan & Blower Motors (HVAC/R) C426V2 - 3/4 HP - 115/230 V - 1725 RPM - Single phase

Century Fan & Blower Motors (HVAC/R) C426V2 - 3/4 HP - 115/230 V - 1725 RPM - Single phase

$477.00 CAD
$477.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : C426V2

Brand : Century

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 3/4 HP

RPM : 1725

Voltage : 115/230 V

Phase : Single

Frame : 56

Mounting : Resilient Base

  • Horsepower :3/4
  • Voltage : 115/230
  • Amps :5.4-5.5/11.0
  • RPM :1725
  • Frequency :60 Hz
  • "C" Dim. :11-5/8"
  • Enclosure :Open Drip-Proof
  • Shaft Dim. :5/8" x 1-7/8"
  • Type :Capacitor Start
  • Speeds :1
  • Diameter :6-1/2"
  • Frame :56
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.25
  • Phase :1
  • Ambient Temp. :40°C
  • Feature(s) :Resilient Base, Class 'B' Insulation, High Starting Torque
  • Weight (lbs.) :26

  • Reference : A.O. Smith C56B18A97 BK1074 RB1074A, Baldor RL1307A, Century C426 C426V1 104601 104642 113965 133953 165414 193914, Dayton 4UB63, Emerson C63CXSBN3923 C63CXSCT3482 C63CXSCT3842 C63CXSEB3787 C63CXTJE4651 3753, Fasco D6086, Franklin Bluffton 10505 1091195700 1101007710, General Electric 5J580GBX 5J580GX 5KC46LN0254 5KC46LN1100 C1483 C231, Marathon 56C17D2061 56C17D2074 B319, I11B1CQ, U.S. Motors 1893
