Century Fan & Blower Motors (HVAC/R) C044 - 1/2 HP - 115/230 V - 1700 RPM - Single phase

Century Fan & Blower Motors (HVAC/R) C044 - 1/2 HP - 115/230 V - 1700 RPM - Single phase

$413.00 CAD
$413.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : C044

Brand : Century

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1/2 HP

RPM : 1700

Voltage : 115/230 V

Phase : Single

Frame : 48Z

Mounting : Resilient Base

  • Horsepower :1/2
  • Voltage :115/230
  • Amps :5.50/2.80
  • RPM :1700
  • Frequency :60 Hz
  • "C" Dim. :11.0"
  • Enclosure :Totally Enclosed, Air Over
  • Shaft Dim. :1/2" x 3.00"
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Diameter :5-5/8"
  • Frame :48Z
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :40°C
  • Capacitor Rating :25MFD-370V
  • Feature(s) :Class 'B' Insulation, Resilient Base, Extended 10-32 Thru-Bolts 3/4" Past Nut, Fully Gasketed
  • Weight (lbs.) :24
  • Reference : A.O. Smith C044, Dayton 4M253, Marathon W48A17T2004, Marathon X026, Universal Electric HF2K032, Universal Electric HF2T005, Universal Electric HF2T7010, A.O. Smith F48Y95A01
