Century Condenser Fan Motors (HVAC/R) 9724 - 1/4 HP - 208/230 V - 1625 RPM - Single phase

Century Condenser Fan Motors (HVAC/R) 9724 - 1/4 HP - 208/230 V - 1625 RPM - Single phase

$252.00 CAD
$252.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 9724

Brand : Century

HVAC : Condenser Fan Motors (HVAC/R)

Horsepower : 1/4 HP

RPM : 1625

Voltage : 208/230 V

Phase : Single

Frame : 42

Mounting : Stud Mount

  • Horsepower :1/4-1/6
  • Voltage :208-230
  • Amps :1.60
  • RPM :1625
  • Frequency :60 Hz
  • Length :4-1/2"
  • "C" Dim. :7-1/2”
  • Enclosure :Totally Enclosed
  • Shaft Dim. :1/2” x 3.00”
  • Type :Permanent Split Capacitor
  • Speeds :1
  • Diameter :5.0"
  • Frame :42
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Thermally Protected
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :60°C
  • Capacitor Rating :5MFD-370V
  • Feature(s) :36” Leads, Extended Mounting Studs, High Efficiency Design, Continuous Duty, Air Over, Class 'B' Insulation, Reversing Plug, All Angle Mount, 60ºC Degree
  • Weight (lbs.) :11
  • Reference : Emerson K48HXCNB1220, General Electric 5KCP29BCA427, 2S004, 5KCP29BCA10, Mars 10724, Universal Electric DF2H016, U.S. Motors 5442H, Trane Tyler D151268P01, JS S82-224
