Century Condenser Fan Motors (HVAC/R) 783A - 1/2 HP - 460V - 1625 RPM - Single phase

Century Condenser Fan Motors (HVAC/R) 783A - 1/2 HP - 460V - 1625 RPM - Single phase

$595.00 CAD
$595.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 783A

Brand : Century

HVAC : Condenser Fan Motors (HVAC/R)

Horsepower : 1/2 HP

RPM : 1625

Voltage : 460 V

Phase : Single

Frame : 48Y

Mounting : Stud Mount

  • Horsepower :1/2
  • Voltage :460
  • Amps :1.60
  • RPM :1625
  • Frequency :60 Hz
  • Length :5-1/4"
  • "C" Dim. :11-1/32"
  • Enclosure :Semi-Enclosed
  • Shaft Dim. :1/2" x 6-1/16"
  • Type :Permanent Split Capacitor
  • Speeds :2
  • Diameter :5-5/8"
  • Frame :48Y
  • Bearings :Ball
  • Rotation :Reversible
  • Protector :Automatic
  • Service Factor :1.00
  • Phase :1
  • Ambient Temp. :60°C
  • Capacitor Rating :7.5MFD-370V
  • Feature(s) :Class 'B' Insulation, Open Lead End, Thru-Bolts, Reversing Plug, Hex mounting hub on both ends for cradle base mounting
  • Weight (lbs.) :16

  • Reference : A.O. Smith F48Z05A01 FH1054 783, Fasco D916, Universal Electric HF2J058N
