Century Fan & Blower Motors (HVAC/R) C523V1 - 1 HP - 115/208-230 V - 1725 RPM - Single phase

Century Fan & Blower Motors (HVAC/R) C523V1 - 1 HP - 115/208-230 V - 1725 RPM - Single phase

$559.00 CAD
$559.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : C523V1

Brand : Century

HVAC : Fan & Blower Motors (HVAC/R)

Horsepower : 1 HP

RPM : 1725

Voltage : 115/208-230 V

Phase : Single

Frame : 56Z

Mounting : Resilient Base


  • Horsepower : 1
  • Amps : 6.2-6.3/12.6
  • Frequency : 60 Hz
  • Length : 9-1/2"
  • "C" Dim. : 11-29/32"
  • Enclosure : Open Drip-Proof
  • Shaft Dim. : 5/8” x 1-7/8"
  • Type : Capacitor Start
  • Speeds : 1
  • Diameter : 6-1/2"
  • Bearings : Ball
  • Rotation : Reversible
  • Protector : Automatic
  • Service Factor : 1.15
  • Ambient Temp. : 40°C
  • Feature(s) : Resilient Base, Class 'B' Insulation, High Starting Torque, Extended Thru-Bolts - Shaft End Only
  • Weight (lbs.) : 32
  • Century C523V1 fan and blower motor designed for HVAC/R ventilation systems. Reliable 1 HP motor operating on 115/208-230V for commercial and residential applications

  • Reference : A.O. Smith Catalogue No. RB1104A, Baldor RL1310A, Century 104600, 165421, 193917, Dayton 3K097, 4UB98, Emerson C63CXSEY3187, 3187C, C63CXSEY3817, 3754, Fasco Catalogue No. D6088, Franklin Bluffton 1101007712, General Electric 4J352BX, 5J581GX1, 5K47SG182, 5KC49NN0061, 5KC49PN0164, 5KCR49PN0343, C1158, C236, Marathon 56C17D5321, 56C17D5340, B310, B311, CU303, BTN56RC17D1M, Leeson 110007.00, 110054.00, Loren Cook I12B1CQ
