Emotortek OEM Replacement Motors (HVAC/R) 99080488 - 1/7 HP - 120 V - 1625 RPM - Single phase

Emotortek OEM Replacement Motors (HVAC/R) 99080488 - 1/7 HP - 120 V - 1625 RPM - Single phase

$304.00 CAD
$304.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 99080488

Brand : Emotortek

HVAC : OEM Replacement Motors (HVAC/R)

Horsepower : 1/7 HP

RPM : 1625

Voltage : 120 V

Phase : Single

Frame : 48

Mounting : Thru-Bolt Mount

  • Horsepower : 1/7
  • Amps : 2.70
  • Frequency : 60 Hz
  • Length : 4-3/32”
  • Enclosure : Open
  • Shaft Dim. : 4-1/8" x 3/8” x 4-1/8”
  • Type : Permanent Split Capacitor
  • Diameter : 3.3”
  • Bearings : Sleeve
  • Rotation : CWLE
  • Protector : Thermally Protected
  • Service Factor : 1.00
  • Ambient Temp. : 40°C
  • Feature(s) : Double Shaft
  • Weight (lbs.) : 6
  • Reference : Broan Nutone L700 HLB6 L700EX L700L 99080750, Universal Electric JE2J052 JE2J052N JE2J067 JE2J067N, 429-482/87, Y5L413C226A, B00AOCM69M
