Emotortek OEM Replacement Motors (HVAC/R) SS9721 - 1/12 HP - 115/208-230 V - 1550 RPM - Single phase

Emotortek OEM Replacement Motors (HVAC/R) SS9721 - 1/12 HP - 115/208-230 V - 1550 RPM - Single phase

$119.00 CAD
$119.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : SS9721

Brand : Emotortek

HVAC : OEM Replacement Motors (HVAC/R)

Horsepower : 1/12 HP

RPM : 1550

Voltage : 115/208-230 V

Phase : Single

Frame : 48

Mounting : Thru-Bolt Mount

  • Horsepower : 1/12
  • RPM : 1550
  • Volts : 115/208-230 V
  • Amps : 1.10 / 0.50
  • Frequency : 60/50 Hz
  • Length : 3-5/8"
  • Enclosure : Open
  • Shaft Dim. : 5/16" x 3-1/4"
  • Type : Permanent Split Capacitor
  • Speeds : 1
  • Diameter : 3.3"
  • Bearings : Ball
  • Rotation : Reversible
  • Protector : Automatic
  • Ambient Temp. : 40°C
  • Capacitor Rating : 4MFD-370V
  • Feature(s) : 50% More Efficient than Shaded Pole Motors, Class 'B' Insulation, Capacitor Included, Includes Lead & Plug Assembly, Reversing Plug, Thru-Bolts
  • Reference : Century 9721, Emerson K33NVDGV1434, Emerson Catalogue No. 9650 9651 9652 9653 9664, Fasco D9721 7163-3371 7190-2652 71902652 7190-2255 7190-2892 7190-2893 7190-2969 7190-3004 7190-3482, Fasco Catalogue No. D1122 D1123 D1127 D1152, SS9721, General Electric 5KSM59JS5036 5KSM59JSK143 5KSM59LS2262, Keeprite 1047779, Rotom US-R90721 R90575 R90721, Universal Electric JA2P275 JE2F029 JE2F030 JE2F035 JF2F008 JA2R143 JA2R161 JA2R178 JA2S004 JA2S006 JA2S044 JE2F035N, 196242, S33P322TB-33, PD1125 PD1127, Y4L403D01G, Xactone X1127
