Century Condenser Fan Motors (HVAC/R) 181651 - 2 HP - 575 V - 1140 RPM - Three phase

Century Condenser Fan Motors (HVAC/R) 181651 - 2 HP - 575 V - 1140 RPM - Three phase

$658.00 CAD
$658.00 CAD
Sale Sold out
Shipping calculated at checkout.
Specifications :

Model : 181651

Brand : Century

HVAC : Condenser Fan Motors (HVAC/R)

Horsepower : 1 HP

RPM : 1140

Voltage : 575 V

Phase : Three

Frame : 56Y

Mounting : Belly Band Mount

  • Horsepower : 2
  • Amps : 2.70
  • Frequency : 60 Hz
  • Length : 10-1/4"
  • "C" Dim. : 12-3/4"
  • Enclosure : Totally Enclosed
  • Shaft Dim. : 5/8” x 2-1/2”
  • Type : Three Phase
  • Speeds : 1
  • Diameter : 6-1/2"
  • Bearings : Ball
  • Rotation : Reversible
  • Protector : Automatic
  • Service Factor : 1.00
  • Ambient Temp. : 60°C
  • Feature(s) : Class 'B' Insulation, Round Body, Thru Bolts
  • Weight (lbs.) : 43
  • Reference : Connections are at opposite shaft end
  • Référence : Carrier HD56AK575, 5K49ZN6125DS, Marathon X526, 5K49ZN6288S, 5K49ZN6317, 5K49ZNG125, 56AA76A50, 173224, 181652, 187027, 193843, 5J996LBX, M0044-3, MA1003
